Next-gen solar cells pass international test standards

A new generation of solar cells that pass international tests for heat and humidity has been developed by Australian researchers.

The researchers from University of Sydney have found a way to stabilise perovskite solar cells, enabling them to pass these strict International Electrotechnical Commission testing standards.

This could result in the solar cells becoming commercially viable for widespread use.

Solar energy systems are now widespread in both industry and domestic housing. Most current systems rely on silicon to convert sunlight into useful energy.

However, the energy conversion rate of silicon in solar panels is close to reaching its natural limits. So, scientists have been exploring new materials that can be stacked on top of silicon in order to improve energy conversion rates. One of the most promising materials to date is a metal halide perovskite, which may even outperform silicon on its own.

"Perovskites are a really promising prospect for solar energy systems," said Professor Anita Ho-Baillie, the inaugural John Hooke Chair of Nanoscience at the University of Sydney.

"They are a very inexpensive, 500 times thinner than silicon and are therefore flexible and ultra-lightweight. They also have tremendous energy-enabling properties and high solar conversion rates."

In experimental form, the past 10 years has seen the performance of perovskites cells improve from low levels to being able to convert 25.2% of energy from the Sun into electricity, comparable to silicon-cell conversion rates, which took 40 years to achieve.

However, unprotected perovskite cells do not have the durability of silicon-based cells, so they are not yet commercially viable.

"Perovskite cells will need to stack up against the current commercial standards. That's what is so exciting about our research. We have shown that we can drastically improve their thermal stability," Ho-Baillie said.

The scientists did this by suppressing the decomposition of the perovskite cells using a simple, low-cost polymer-glass blanket.

The work was led by Professor Ho-Baillie, while Dr Lei Shi conducted the experimental work in Ho-Baillie's research group in the School of Photovoltaic and Renewable Energy Engineering at the University of New South Wales.

Under continual exposure to the Sun and other elements, solar panels experience extremes of heat and humidity. Experiments have shown that under such stress, unprotected perovskite cells become unstable, releasing gas from within their structures.

"Understanding this process, called 'outgassing', is a central part of our work to develop this technology and to improve its durability," Ho-Baillie said.

Low-cost solution

The research team used gas chromatography-mass spectrometry (GC-MS) to identify the signature volatile products and decomposition pathways of the thermally stressed hybrid perovskites commonly used in high-performance cells. Using this method, they found that a low-cost polymer-glass stack with a pressure-tight seal was effective in suppressing the perovskite 'outgassing', the process that leads to its decomposition.

When put to strict international testing standards, the cells the team were working on outperformed expectations.

"Another exciting outcome of our research is that we are able to stabilise perovskite cells under the harsh International Electrotechnical Commission standard environmental testing conditions. Not only did the cells pass the thermal cycling tests, they exceeded the demanding requirements of damp-heat and humidity-freeze tests as well," Ho-Baillie said.

These tests help determine if solar cell modules can withstand the effects of outdoor operating conditions by exposing them to repeated temperature cycling between -40 and 85°, as well as exposure to 85% relative humidity.

Specifically, the perovskite solar cells survived more than 1800 hours of the IEC damp-heat test and 75 cycles of the humidity freeze test, exceeding the requirement of the IEC61215:2016 standard for the first time.

"We expect this work will contribute to advances for stabilising perovskite solar cells, increasing their commercialisation prospects," Ho-Baillie said.

The research findings were published in the journal Science.
